| AXIFLOW - ALYS Silica Columns |
|---|
ALYS Silica columns are made with spherical, highly pure silica particles (99.999% Pure). ALYS Silica is the basis for our high quality ALYS stationary Phase manufactured to provide maximum bonded phase coverage. ALYS Silica column provides excellent peak shapes using simple eluents while operating at low pressure.
| Technical Details: | |||
|---|---|---|---|
| Silica type | Spherical | ||
| Silica Purity | 99.999% | ||
| Carbon Load | 0% | ||
| Surface Area | 450 m2/gram | ||
| Pore Size | 100 Å | ||
| PH Range | 2.0-6.0 | ||
| Particle Size | 3µm, 3.5µm, 5µm and 10µm | ||
Applications :
Application Of Uracil and Alkylbenzenes
Compound Name : 1. Uracil | 2. Toluene | 3. Propylbenzene | 4. pentylbenzene
| Ordering Information | ||||
|---|---|---|---|---|
| Part Number | Phase | Particle Size (µm) |
Length (mm) |
ID (mm) |
| ALS.Si.46.300.0500 | ALYS Silica | 5 | 300 | 4.6 |
| ALS.Si.40.300.0500 | ALYS Silica | 5 | 300 | 4 |
| ALS.Si.46.250.0500 | ALYS Silica | 5 | 250 | 4.6 |
| ALS.Si.40.250.0500 | ALYS Silica | 5 | 250 | 4 |
| ALS.Si.30.250.0500 | ALYS Silica | 5 | 250 | 3 |
| ALS.Si.20.250.0500 | ALYS Silica | 5 | 250 | 2 |
| ALS.Si.10.250.0500 | ALYS Silica | 5 | 250 | 1 |
| ALS.Si.46.200.0500 | ALYS Silica | 5 | 200 | 4.6 |
| ALS.Si.40.200.0500 | ALYS Silica | 5 | 200 | 4 |
| ALS.Si.30.200.0500 | ALYS Silica | 5 | 200 | 3 |
| ALS.Si.20.200.0500 | ALYS Silica | 5 | 200 | 2 |
| ALS.Si.10.200.0500 | ALYS Silica | 5 | 200 | 1 |
| ALS.Si.46.150.0500 | ALYS Silica | 5 | 150 | 4.6 |
| ALS.Si.40.150.0500 | ALYS Silica | 5 | 150 | 4 |
| ALS.Si.30.150.0500 | ALYS Silica | 5 | 150 | 3 |
| ALS.Si.20.150.0500 | ALYS Silica | 5 | 150 | 2 |
| ALS.Si.10.150.0500 | ALYS Silica | 5 | 150 | 1 |
| ALS.Si.46.125.0500 | ALYS Silica | 5 | 125 | 4.6 |
| ALS.Si.40.125.0500 | ALYS Silica | 5 | 125 | 4 |
| ALS.Si.30.125.0500 | ALYS Silica | 5 | 125 | 3 |
| ALS.Si.20.125.0500 | ALYS Silica | 5 | 125 | 2 |
| ALS.Si.10.125.0500 | ALYS Silica | 5 | 125 | 1 |
| ALS.Si.46.100.0500 | ALYS Silica | 5 | 100 | 4.6 |
| ALS.Si.40.100.0500 | ALYS Silica | 5 | 100 | 4 |
| ALS.Si.30.100.0500 | ALYS Silica | 5 | 100 | 3 |
| ALS.Si.20.100.0500 | ALYS Silica | 5 | 100 | 2 |
| ALS.Si.10.100.0500 | ALYS Silica | 5 | 100 | 1 |
| ALS.Si.46.75.0500 | ALYS Silica | 5 | 75 | 4.6 |
| ALS.Si.40.75.0500 | ALYS Silica | 5 | 75 | 4 |
| ALS.Si.30.75.0500 | ALYS Silica | 5 | 75 | 3 |
| ALS.Si.20.75.0500 | ALYS Silica | 5 | 75 | 2 |
| ALS.Si.10.75.0500 | ALYS Silica | 5 | 75 | 1 |
| ALS.Si.46.50.0500 | ALYS Silica | 5 | 50 | 4.6 |
| ALS.Si.40.50.0500 | ALYS Silica | 5 | 50 | 4 |
| ALS.Si.30.50.0500 | ALYS Silica | 5 | 50 | 3 |
| ALS.Si.20.50.0500 | ALYS Silica | 5 | 50 | 2 |
| ALS.Si.10.50.0500 | ALYS Silica | 5 | 50 | 1 |
| ALS.Si.46.33.0500 | ALYS Silica | 5 | 33 | 4.6 |
| ALS.Si.40.33.0500 | ALYS Silica | 5 | 33 | 4 |
| ALS.Si.30.33.0500 | ALYS Silica | 5 | 33 | 3 |
| ALS.Si.20.33.0500 | ALYS Silica | 5 | 33 | 2 |
| ALS.Si.10.33.0500 | ALYS Silica | 5 | 33 | 1 |
| ALS.Si.46.30.0500 | ALYS Silica | 5 | 30 | 4.6 |
| ALS.Si.40.30.0500 | ALYS Silica | 5 | 30 | 4 |
| ALS.Si.30.30.0500 | ALYS Silica | 5 | 30 | 3 |
| ALS.Si.20.30.0500 | ALYS Silica | 5 | 30 | 2 |
| ALS.Si.10.30.0500 | ALYS Silica | 5 | 30 | 1 |
| ALS.Si.20.20.0500 | ALYS Silica | 5 | 20 | 2 |
| ALS.Si.46.300.0300 | ALYS Silica | 3 | 300 | 4.6 |
| ALS.Si.40.300.0300 | ALYS Silica | 3 | 300 | 4 |
| ALS.Si.46.250.0300 | ALYS Silica | 3 | 250 | 4.6 |
| ALS.Si.40.250.0300 | ALYS Silica | 3 | 250 | 4 |
| ALS.Si.30.250.0300 | ALYS Silica | 3 | 250 | 3 |
| ALS.Si.20.250.0300 | ALYS Silica | 3 | 250 | 2 |
| ALS.Si.10.250.0300 | ALYS Silica | 3 | 250 | 1 |
| ALS.Si.46.200.0300 | ALYS Silica | 3 | 200 | 4.6 |
| ALS.Si.40.200.0300 | ALYS Silica | 3 | 200 | 4 |
| ALS.Si.30.200.0300 | ALYS Silica | 3 | 200 | 3 |
| ALS.Si.20.200.0300 | ALYS Silica | 3 | 200 | 2 |
| ALS.Si.10.200.0300 | ALYS Silica | 3 | 200 | 1 |
| ALS.Si.46.150.0300 | ALYS Silica | 3 | 150 | 4.6 |
| ALS.Si.40.150.0300 | ALYS Silica | 3 | 150 | 4 |
| ALS.Si.30.150.0300 | ALYS Silica | 3 | 150 | 3 |
| ALS.Si.20.150.0300 | ALYS Silica | 3 | 150 | 2 |
| ALS.Si.10.150.0300 | ALYS Silica | 3 | 150 | 1 |
| ALS.Si.46.125.0300 | ALYS Silica | 3 | 125 | 4.6 |
| ALS.Si.40.125.0300 | ALYS Silica | 3 | 125 | 4 |
| ALS.Si.30.125.0300 | ALYS Silica | 3 | 125 | 3 |
| ALS.Si.20.125.0300 | ALYS Silica | 3 | 125 | 2 |
| ALS.Si.10.125.0300 | ALYS Silica | 3 | 125 | 1 |
| ALS.Si.46.100.0300 | ALYS Silica | 3 | 100 | 4.6 |
| ALS.Si.40.100.0300 | ALYS Silica | 3 | 100 | 4 |
| Ordering Information | ||||
|---|---|---|---|---|
| Part Number | Phase | Particle Size (µm) |
Length (mm) |
ID (mm) |
| ALS.Si.30.100.0300 | ALYS Silica | 3 | 100 | 3 |
| ALS.Si.20.100.0300 | ALYS Silica | 3 | 100 | 2 |
| ALS.Si.10.100.0300 | ALYS Silica | 3 | 100 | 1 |
| ALS.Si.46.75.0300 | ALYS Silica | 3 | 75 | 4.6 |
| ALS.Si.40.75.0300 | ALYS Silica | 3 | 75 | 4 |
| ALS.Si.30.75.0300 | ALYS Silica | 3 | 75 | 3 |
| ALS.Si.20.75.0300 | ALYS Silica | 3 | 75 | 2 |
| ALS.Si.10.75.0300 | ALYS Silica | 3 | 75 | 1 |
| ALS.Si.46.50.0300 | ALYS Silica | 3 | 50 | 4.6 |
| ALS.Si.40.50.0300 | ALYS Silica | 3 | 50 | 4 |
| ALS.Si.30.50.0300 | ALYS Silica | 3 | 50 | 3 |
| ALS.Si.20.50.0300 | ALYS Silica | 3 | 50 | 2 |
| ALS.Si.10.50.0300 | ALYS Silica | 3 | 50 | 1 |
| ALS.Si.46.33.0300 | ALYS Silica | 3 | 33 | 4.6 |
| ALS.Si.40.33.0300 | ALYS Silica | 3 | 33 | 4 |
| ALS.Si.30.33.0300 | ALYS Silica | 3 | 33 | 3 |
| ALS.Si.20.33.0300 | ALYS Silica | 3 | 33 | 2 |
| ALS.Si.10.33.0300 | ALYS Silica | 3 | 33 | 1 |
| ALS.Si.46.30.0300 | ALYS Silica | 3 | 30 | 4.6 |
| ALS.Si.40.30.0300 | ALYS Silica | 3 | 30 | 4 |
| ALS.Si.30.30.0300 | ALYS Silica | 3 | 30 | 3 |
| ALS.Si.20.30.0300 | ALYS Silica | 3 | 30 | 2 |
| ALS.Si.10.30.0300 | ALYS Silica | 3 | 30 | 1 |
| ALS.Si.20.20.0300 | ALYS Silica | 3 | 20 | 2 |
| ALS.Si.46.300.1000 | ALYS Silica | 10 | 300 | 4.6 |
| ALS.Si.40.300.1000 | ALYS Silica | 10 | 300 | 4 |
| ALS.Si.46.250.1000 | ALYS Silica | 10 | 250 | 4.6 |
| ALS.Si.40.250.1000 | ALYS Silica | 10 | 250 | 4 |
| ALS.Si.30.250.1000 | ALYS Silica | 10 | 250 | 3 |
| ALS.Si.20.250.1000 | ALYS Silica | 10 | 250 | 2 |
| ALS.Si.10.250.1000 | ALYS Silica | 10 | 250 | 1 |
| ALS.Si.46.200.1000 | ALYS Silica | 10 | 200 | 4.6 |
| ALS.Si.40.200.1000 | ALYS Silica | 10 | 200 | 4 |
| ALS.Si.30.200.1000 | ALYS Silica | 10 | 200 | 3 |
| ALS.Si.20.200.1000 | ALYS Silica | 10 | 200 | 2 |
| ALS.Si.10.200.1000 | ALYS Silica | 10 | 200 | 1 |
| ALS.Si.46.150.1000 | ALYS Silica | 10 | 150 | 4.6 |
| ALS.Si.40.150.1000 | ALYS Silica | 10 | 150 | 4 |
| ALS.Si.30.150.1000 | ALYS Silica | 10 | 150 | 3 |
| ALS.Si.20.150.1000 | ALYS Silica | 10 | 150 | 2 |
| ALS.Si.10.150.1000 | ALYS Silica | 10 | 150 | 1 |
| ALS.Si.46.125.1000 | ALYS Silica | 10 | 125 | 4.6 |
| ALS.Si.40.125.1000 | ALYS Silica | 10 | 125 | 4 |
| ALS.Si.30.125.1000 | ALYS Silica | 10 | 125 | 3 |
| ALS.Si.20.125.1000 | ALYS Silica | 10 | 125 | 2 |
| ALS.Si.10.125.1000 | ALYS Silica | 10 | 125 | 1 |
| ALS.Si.46.100.1000 | ALYS Silica | 10 | 100 | 4.6 |
| ALS.Si.40.100.1000 | ALYS Silica | 10 | 100 | 4 |
| ALS.Si.30.100.1000 | ALYS Silica | 10 | 100 | 3 |
| ALS.Si.20.100.1000 | ALYS Silica | 10 | 100 | 2 |
| ALS.Si.10.100.1000 | ALYS Silica | 10 | 100 | 1 |
| ALS.Si.46.75.1000 | ALYS Silica | 10 | 75 | 4.6 |
| ALS.Si.40.75.1000 | ALYS Silica | 10 | 75 | 4 |
| ALS.Si.30.75.1000 | ALYS Silica | 10 | 75 | 3 |
| ALS.Si.20.75.1000 | ALYS Silica | 10 | 75 | 2 |
| ALS.Si.10.75.1000 | ALYS Silica | 10 | 75 | 1 |
| ALS.Si.46.50.1000 | ALYS Silica | 10 | 50 | 4.6 |
| ALS.Si.40.50.1000 | ALYS Silica | 10 | 50 | 4 |
| ALS.Si.30.50.1000 | ALYS Silica | 10 | 50 | 3 |
| ALS.Si.20.50.1000 | ALYS Silica | 10 | 50 | 2 |
| ALS.Si.10.50.1000 | ALYS Silica | 10 | 50 | 1 |
| ALS.Si.46.33.1000 | ALYS Silica | 10 | 33 | 4.6 |
| ALS.Si.40.33.1000 | ALYS Silica | 10 | 33 | 4 |
| ALS.Si.30.33.1000 | ALYS Silica | 10 | 33 | 3 |
| ALS.Si.20.33.1000 | ALYS Silica | 10 | 33 | 2 |
| ALS.Si.10.33.1000 | ALYS Silica | 10 | 33 | 1 |
| ALS.Si.46.30.1000 | ALYS Silica | 10 | 30 | 4.6 |
| ALS.Si.40.30.1000 | ALYS Silica | 10 | 30 | 4 |
| ALS.Si.30.30.1000 | ALYS Silica | 10 | 30 | 3 |
| ALS.Si.20.30.1000 | ALYS Silica | 10 | 30 | 2 |
| ALS.Si.10.30.1000 | ALYS Silica | 10 | 30 | 1 |
| ALS.Si.20.20.1000 | ALYS Silica | 10 | 20 | 2 |
